Ld systems MIX 10 A G3
- Bewertungen lesen (0)
- Zugehöriges Zubehör
- Ähnliche Produkte
- Kostenlose Lieferung
- Günstige Preise garantiert
- Zufrieden oder erstattet
- 3 Jahre Garantie
- Ref : 80801
Lieferbar
1 Zimmer frei.
innerhalb von 24 Stunden lieferbar
Lagerbestand
Nicht im Geschäft erhältlich
Die Marke Ld systems
Erfahren Sie mehr über die Marke Ld systems und entdecken Sie den gesamten Katalog.
Shopping Guide Sono Equipment
Leistung, Lautsprechergröße, Preis, Abmessungen, passive oder aktive Version.... Die Wahl eines Lautsprechers ist keine leichte Aufgabe! Die Fülle an Modellen und Technologien verwirrt oft uneingeweih
Wenden Sie sich an einen Experten
Unsere musikbegeisterten und begeisterten Teleberater sind hier, um alle Ihre Fragen zu beantworten.
Mobile pa-systeme
The lD Systems MIX 10AG3 is a portable amplified speaker of 2x200 Watts.
The Mix 10AG3 incorporates a 7-channel mixer and Class D amplifier with 2 x 400 watts of power.
The compact bass-reflex speaker features a custom woofer and 1 "10" Celestion HF driver complement, frequency response from 65 Hz to 20 kHz and 90 ° x 60 ° dispersion.
Hosting a wide variety of input sources, including electronic instruments, smartphones, tablets, MP3 players and CDs, the built-in mixer provides 3-channel mic with 2-band EQ, 48 V phantom power.
The output section includes a 3-band master equalizer.
the LD 10 MIX A G3 incorporates a DSP with 16 effect presets, and overcurrent limiter, overload, short circuit and thermal protection.
A speakON output is used to power the passive LD MIX 10 G3 to easily create a stereo configuration.
Constructed of heavy duty plywood with a 50 ° control angle and a dual tilt pole receptacle for 0 ° or 5 ° mounting angles. Alone or in tandem with the passive unit, the LD MIX 10 G3 delivers exceptional performance and versatility in a lightweight, easy-to-carry package.
The Mix 10AG3 incorporates a 7-channel mixer and Class D amplifier with 2 x 400 watts of power.
The compact bass-reflex speaker features a custom woofer and 1 "10" Celestion HF driver complement, frequency response from 65 Hz to 20 kHz and 90 ° x 60 ° dispersion.
Hosting a wide variety of input sources, including electronic instruments, smartphones, tablets, MP3 players and CDs, the built-in mixer provides 3-channel mic with 2-band EQ, 48 V phantom power.
The output section includes a 3-band master equalizer.
the LD 10 MIX A G3 incorporates a DSP with 16 effect presets, and overcurrent limiter, overload, short circuit and thermal protection.
A speakON output is used to power the passive LD MIX 10 G3 to easily create a stereo configuration.
Constructed of heavy duty plywood with a 50 ° control angle and a dual tilt pole receptacle for 0 ° or 5 ° mounting angles. Alone or in tandem with the passive unit, the LD MIX 10 G3 delivers exceptional performance and versatility in a lightweight, easy-to-carry package.
Lire la suite
Technisches Arbeitsblatt
- Product Type PA Speaker
- Active Type
- 10 "boomer diameter
- Boomer diameter 254 mm
- Custom made boomer brand
- Diameter tweeter 1 "
- Tweeter diameter (mm) 25.4 mm
- Brand tweeter Celestion
- Dispersion angle (H x V) 80 x 70 °
- Frequency response 65 - 20,000 Hz
- Class D amplifier
- Amplifier power (eff.) 2 x 200 W
- Amplifier power (peak) 2 x 400 W
- Maximum sound pressure level 124 dB
- Protection circuits Short-circuit, Limiter, Overload, Overvoltage.
- Mix table
- Channels 7
- Micro inputs 3
- XLR 1/4 "microphone inputs, XLR
- DFX Send, EQ Hi, EQ Low, Level, Hi-Z (Channel 1 only) Mic Input Controls
- Line 2 inputs
- Line Input Connectors 2 x XLR, 3.5mm TRS
- Level Line Input Controls
- High impedance input (Hi-Z) 1
- High impedance input connector (Hi-Z) 6.35 mm jack
- High Impedance Input Impedance (Hi-Z) 1000 kohms
- Monitor Output, Line Level 2
- XLR Line Monitor Output Connector
- Monitor Line Outputs volume knob potentiometer, - - level control of the subwoofer
- Maximum Level of Monitor Output 17 dBu
- Number of Record 1 Outputs
- Main Output Power (Amplifier), 4 Ohm 200 W
- Box
- Bass Reflex cabinet finish
- Material box 16 mm Plywood
- Surface of the box Painted structured paint
- Color black box
- Width 315 mm
- Height (mm) 489 mm
- Depth 307 mm
- Weight 12,3 kg
- Other Bluetooth properties, Ergonomic handle, Footwell with reclining device (0 ° / 5 °)
